2.4Ghz 100W customized portable RF amplifier module for anti UAV/drone system
Product Description
Parameters:
| Indicators |
Parameter |
| Working frequency |
2400-2500MHz |
| Gain |
≥50dBm |
| Max output |
≥50dBm |
| Output CW saturation power |
≥100W |
| Including inside gain flatness |
≤1±0.5dBm |
| Working current |
≤8-12A |
| Output port standing wave |
≤1.5 |
| Clutter suppression |
≥65dBm |
| Harmonic suppression |
≥11dBm |
| Rf output interface |
SMA / Female N |
| 27V power supply port |
VA3.96-2A/2Y |
| Sweep frequency |
60-250KHz |
| VCC Power supply reference |
24V-27V |
| Max Voltage |
+30V |
| Weight |
0.9kg |
| Installation dimensions |
188*98mm |
| Overall dimensions |
199*119*25mm |
| Operating temperature |
-25℃ ~ +5℃ |
| Installation |
Installing radiator for testing of power amplifier |
| Standing wave protection |
Turn off the power amplifier to protect standing wave when don't connected antenna |
| Temperature protection |
Over 80℃ automatically turn off power amplifier |
| Communication |
The power amplifier has RS485 communication function |
