| Channel | Working frequency | Output power(±1dBm) | |
| 2.4G | 2400-2500MHz | 45 dBm(30W) | |
| 2.4G | 2400-2500MHz | 46 dBm(40W) | |
| 5.8G | 5725-5850MHz | 45 dBm(33W) | |
| GPS L1 | 1570-1620MHz | 46 dBm(35W) | |
| GPS L2 | 2400-2500MHz | 46 dBm(33.5W) | |
| Total output power: 170W | |||
| Power consumption : 400W | |||
| Power supply: AC90-260V, DC24-28V | |||
| Main engine weight : 16.8Kg | |||
| Size:350×190×490mm | |||
| With directional panel antenna 10dBi (jamming range 1.2km-1.5km) or 5pcs omni antenna 7dBi (jamming range 600m-800m) |
|||
| Jammer Module Number : | 5 | ||
| Cooling System: | Systematic Smart Cooling System | ||
| Jamming Source : | Noise Technology | ||
| Humidity: 30%-95% | |||
| Running temperature : -20ºC to +70ºC | |||
| Inside battery working 1.5h: 24V,24A | |||
| Battery charger: 5A(Open the external switch to charge, automatically manage the charging current, full automatically disconnect) | |||
| External Remote control Panel : shows the battery voltage, can switch on/off each band. | |||
12 months from date of shipment
Longer warranty available on request
Packing list
| Name | Quantity | Remarks |
| Jammer | 1 | |
| DC24V Charger | 1 | AC110V-240V Input |
| Instruction / Certificate | 1 | |
| Spare battery | Optional |
