The antenna must be connected before switching on the power supply. Do not remove the antenna when the host is working.
Whether the device is in use or not, please charge the device once every half month to ensure the performance of the battery.
|
Number |
Items |
Specifications |
|
1 |
Frequency Range |
700-1000MHz+2.4Ghz |
|
2 |
Output Power |
30W+30W（45dBm） |
|
3 |
Working Time |
50mins |
|
4 |
Waterproof |
IP68 |
|
5 |
Battery Capacity Tester |
LCD Screen |
|
6 |
Battery Voltage |
28V 3000mAh |
|
7 |
Current |
|
|
8 |
Efficiency |
55%@46dBm |
|
9 |
Operating Temperature |
‘-30℃～65℃ |
|
10 |
Storage Temperature |
’-40℃～120℃ |
|
11 |
Operating Humidity |
＜95%RH |
|
12 |
RF PORT |
N-Female |
|
13 |
Power Socket |
IP68 Aviation Plug |
|
14 |
RF ON/OFF Button |
Yes |
|
15 |
LCD Screen Button |
Yes |
|
16 |
Color |
Green |
|
17 |
Shell Material |
Aluminum |
|
18 |
Shell Size |
177*85*43mm |
|
19 |
Net Weight |
1.2Kg |
|
20 |
Installation to Tripod |
3/8 Female |
|
|
|
|
|
Amni Antenna |
3dBi size: φ20*300mm |
2pcs |
|
Power Adapter |
28V/2A |
1pcs |
|
Installation to Tripod |
3/8 to 1/4 Screw Adapter |
1pcs |
|
Molle Bag |
200*95*48mm |
1pcs |
| Quantity(PCS) | <100pcs | <500 | 500-1000 | >1000 |
| Lead time(Days) | 3 | 3-5 | 7-12 | To be negotiated |
| Item | Logo | Frequency | Power | Packing |
| MOQ(PCS) | 1 | 1 | 1 | 1 |
Packing and Delivery
