1 Main functions
1. 12-channel type can efficiently provide shield for mobile signals from CDMA, GSM, DCS, PCS, WCDMA and PHS;
1.2 It Only shields the signals from mobile phone and does not affect the normal operation of other electronic devices;
1.3 Generally, please use your mobile phone at places more than 200 meters away from the base station;
1.4 Switching on, it can work stably for a long time;
1.5 Slow start-up circuit can avoid sparkling caused by mechanical switch.
2 Technical parameters
2.1 Effective isolating/shielding diameter: 100meters
2.2 lsolating signal bandwidth
2.3 Working time: it can work stably for a long time
2.4 Environment temperature:-40 ºC to +55 ºC
2.5 Relative humidity; 30%-- 95%
2.6 Power adapter: input AC 110V-240V
Parameters
|
Frequency
|
Output power
|
GSM
|
925-960MHz
|
10W
|
CDMA
|
865-885MHz
|
10W
|
DCS/PHS
|
1805-1920MHz
|
10W
|
3G/WCDMA
|
2010-2170MHz
|
10W
|
4G1/4G/E
|
2300-2390MHz
|
10W
|
WIFI2.4G
|
2400-2485MHz
|
10W
|
4G2/4G/D
|
2515-2675MHz
|
10W
|
5G 1
|
3400-3600MHz
|
10W
|
5G 2
|
4800-4900MHz
|
10W
|
5G(broadcasting)
|
750-803MHz
|
10W
|
5.2WIFI
|
5150-5350MHz
|
10W
|
5.8WIFI
|
5725-5850MHz
|
10W
|
Ambient temperature
|
(-20ºC to +55ºC)
|
|
Relative humidity
|
30%-95%
|
|
Power Supply
|
Input AC 110V-220V
|
|
