Name: 2.4Ghz 100W customized portable RF amplifier module for anti UAV/droner system
Brand: Anti-Drone System Solution
Availability: InStock
Rating: 5 (1 reviews)

Home > Power Amplifer Module > Ldmos module > 2.4G module

2.4Ghz 100W customized portable RF amplifier module for anti UAV/droner system

Description Review

Description

Essential details

Model Number:: TTSK-2.4G-100W

Type:: RF Module, RF power amplifier module

Place of Origin:: Guangdong, China

Brand Name:: Tatusky

Supplier Type:: OEM/ODM

Working frequency:: 2400-2500MHz

Gain:: ≥50dBm

VCC Power supply reference:: 24V-27V

Output CW saturation power:: ≥100W

Including inside gain flatness:: ≤1±0.5dBm

Working current:: ≤8-12A

Operating temperature:: -25℃ ~ +85℃

Net Weight:: 0.9kg

Size:: 199*119*25mm

Supply Ability

Supply Ability: 8000 Piece/Pieces per Month

Packaging & delivery

Packaging Details

Standard Package

Port

ShenZhen, Guangzhou

Lead time:

Quantity(pieces)	1 - 50	51 - 100	>100
Lead time (days)	6	8	To be negotiated

2.4Ghz 100W customized portable RF amplifier module for anti UAV/drone system

Product Description

Parameters:

Review

* Name

* E-mail

Your rating

* Subject

* Message

* Verification code

Add your images
Please only provide JPG/GIF/PNG files. Individual photo size cannot exceed 2MB.

1/3

Send your message to us

* Email

* Country

please select your country

Afghanistan
Aland Islands
Albania
Algeria
American Samoa
Andorra
Angola
Anguilla
Antigua and Barbuda
Argentina
Armenia
Aruba
Australia
Austria
Azerbaijan
Bahamas
Bahrain
Bangladesh
Barbados
Belarus
Belgium
Belize
Benin
Bermuda
Bhutan
Bolivia
Bosnia and Herzegovina
Botswana
Bouvet Island
Brazil
British Indian Ocean Territory
British Virgin Islands
Brunei Darussalam
Bulgaria
Burkina Faso
Burundi
Cambodia
Cameroon
Canada
Cape Verde
Caribbean Netherlands
Cayman Islands
Central African Republic
Chad
Chile
China
Christmas Island
Cocos Islands
Colombia
Comoros
Congo
Cook Islands
Costa Rica
Cote D'ivoire
Cuba
Curaçao
Cyprus
Czech Republic
Democratic People's Republic of Korea
Democratic Republic of the Congo
Denmark
Djibouti
Dominica
East Timor
Ecuador
Egypt
El Salvador
Equatorial Guinea
Eritrea
Estonia
Ethiopia
Falkland Islands
Faroe Islands
Fiji
Finland
France
French Guiana
French Polynesia
French Southern Territories
Gabon
Gambia
Georgia
Germany
Ghana
Gibraltar
Greece
Greenland
Grenada
Guadeloupe
Guam
Guatemala
Guernsey
Guinea
Guinea-Bissau
Guyana
Haiti
Heard Island and Mcdonald Islands
Honduras
Hong Kong, China
Hungary
Iceland
India
Indonesia
Iran
Iraq
Ireland
Isle of Man
Israel
Italy
Jamaica
Japan
Jordan
Kazakhstan
Kenya
Kiribati
Korea
Kosovo
Kuwait
Kyrgyzstan
Laos
Latvia
Lebanon
Lesotho
Liberia
Liechtenstein
Lithuania
Luxembourg
Macau, China
Macedonia
Madagascar
Malawi
Malaysia
Maldives
Mali
Malta
Marshall Islands
Martinique
Mauritania
Mauritius
Mayotte
Mexico
Micronesia
Moldova
Monaco
Mongolia
Montenegro
Montserrat
Morocco
Mozambique
Myanmar
Namibia
Nauru
Nepal
Netherlands
Netherlands Antilles
New Caledonia
New Zealand
Nicaragua
Niger
Nigeria
Niue
Norfolk Island
Northern Mariana Islands
Norway
Oman
Pakistan
Palau
Palestine
Panama
Papua New Guinea
Paraguay
Peru
Philippines
Pitcairn Islands
Poland
Portugal
Puerto Rico
Qatar
Reunion
Romania
Russia
Rwanda
Saint Barthélemy
Saint Helena
Saint Kitts and Nevis
Saint Lucia
Saint Martin
Saint Pierre and Miquelon
Saint Vincent and the Grenadines
San Marino
Sao Tome and Principe
Saudi Arabia
Senegal
Serbia
Seychelles
Sierra Leone
Singapore
Sint Maarten
Slovakia
Slovenia
Solomon Islands
Somalia
South Africa
South Georgia and The South Sandwich Islands
Spain
Sri Lanka
State of Libya
Sudan
Suriname
Svalbard and Jan Mayen
Swaziland
Sweden
Switzerland
Syrian Arab Republic
TaiWan, China
Tajikistan
Tanzania
Thailand
The Republic of Croatia
Togo
Tokelau
Tonga
Trinidad and Tobago
Tunisia
Turkey
Turkmenistan
Turks and Caicos Islands
Tuvalu
Uganda
Ukraine
United Arab Emirates
United Kingdom
United States
United States Minor Outlying Islands
Uruguay
US Virgin Islands
Uzbekistan
Vanuatu
Vatican City State
Venezuela
Vietnam
Wallis and Futuna Islands
Western Sahara
Western Samoa
Yemen
Zambia
Zimbabwe

* Message

Indicators	Parameter
Working frequency	2400-2500MHz
Gain	≥50dBm
Max output	≥50dBm
Output CW saturation power	≥100W
Including inside gain flatness	≤1±0.5dBm
Working current	≤8-12A
Output port standing wave	≤1.5
Clutter suppression	≥65dBm
Harmonic suppression	≥11dBm
Rf output interface	SMA / Female N
27V power supply port	VA3.96-2A/2Y
Sweep frequency	60-250KHz
VCC Power supply reference	24V-27V
Max Voltage	+30V
Weight	0.9kg
Installation dimensions	188*98mm
Overall dimensions	19911925mm
Operating temperature	-25℃ ~ +5℃
Installation	Installing radiator for testing of power amplifier
Standing wave protection	Turn off the power amplifier to protect standing wave when don't connected antenna
Temperature protection	Over 80℃ automatically turn off power amplifier
Communication	The power amplifier has RS485 communication function
