| Indicators | Parameters |
| Operating frequency | 10MHz-600MHz |
| gain | 253dB |
| Input power | 3±1 dBm |
| Maximum input | +10dBm |
| Output CW saturated power | <250W |
| In-band gain flatness | <4+1dB |
| Temperature protection | 80 degree protection |
| Working current | <20A |
| Input port standing wave | <1.8 |
| Clutter suppression | 265dBc |
| Harmonic suppression | 210dBc |
| Rfinput interface | SMA-F |
| Rf output interface | N-K |
| 48V power supply port | Through-core capacitor |
| Power amplifier PTT switch port | Power amplifier off by default 5V on |
| VCC power supply reference | 48V/25A |
| VCC Maximum voltage | +50V |
| Overall dimensions without connectors | <211x100 x 28 units: mm |
| Operating temperature | -25℃~+55℃ |
| Installation mode | A heat sink is required for the power amplifier test |
