The TTSKW07 adopts a low-power design and highly integrated design, capable of detecting mainstream DJI, AUTEL and other rotary wing drones using OFDM high-definition image transmission, as well as various DIY crossings using analog image transmission signals.
Tatusky offers a full range of drone/pilot detection and identification. Our products are developed and manufactured in China.
|
Name |
Related parameters |
|
Receiving frequency band |
300MHz-6200MHz |
|
Identify type |
OFDM high-definition image transmission signal, time traveling machine FM analog image transmission |
|
Detecting distance |
≥1km |
|
Detection sensitivity |
Better than -96dBm |
|
Detecting alarm methods |
Headphones, sound and light |
|
Log recording |
Support no less than 500 alarm records |
|
Upgrade and data export interface |
type-c |
|
power supply |
Detachable lithium battery (Type-C charging) |
|
Battery life |
≥ 6 hours (single battery) |
|
structure size |
≤ 135mm × 60mm × 35mm (host without antenna) |
|
Working weight |
≤ 500g (including single battery) |
|
Startup method |
Knob button, rotate to start |
|
Control method |
Key operation, supporting sound adjustment, screen backlight on, and drone detection information viewing function |
ü Passive Detection of Drones: Able to identify rotary wing drones such as DJI and Autel that use OFDM high-definition image transmission. It can detect various types of time traveling machines using analog image transmission within 300MHz-6200MHz.
ü Sound and light alarm: headphone sound alarm, external sound and light alarm.
ü Log recording: It has alarm log recording and can export alarm logs through USB interface.
ü Headphone function: capable of obtaining alarm sound through headphones.
ü Firmware upgrade function: Upgrade firmware through the Type-C interface.
ü Multi language switching: supports English and Russian.
ü Work status display: time, battery level, equipment status
ü Working modes: default mode, key frequency band scanning mode (later supported), user-defined feature library scanning mode (later supported).
ü Custom detection: Users can modify, delete, or add detection drone feature libraries through the type-C interface.
