1.Supports DJI OC1/2/3 protocol drone detection and decoding, and can obtain drone GPS coordinates, pilot GPS coordinates, return point GPS coordinates, drone model and unique serial number and other parameters.
2.Supports DJI O4 detection, outputs ID, and outputs encrypted 176 bytes for online decryption.
3.A single drone outputs about 80 messages per minute at a constant speed;
4.Detection range: 2-15 km.
5. Number of drones detected simultaneously: >10.
6.UDP reports the detection results to the local computer, and TCP can also be used to transmit them to the cloud.
7.Type 5V power supply, power consumption 3.5 W.
8.Size: 89mm* 55mm *18mm
|
Common commands |
|
|
start |
Default Command |
|
-gain xx -longi xxxx, -lati xxxx, -o4byte 1 -freq 2.4 -freq 5.8 |
Set gain [10 70] Set the current location longitude Set the current location latitude Output encrypted O4 176 bytes Scan only 2.4G Scan only 5.8G |
|
example |
start -gain 70 -longi 121.498, -lati 31.33, -o4byte 1 |
It can decode the coordinates of the drone, the coordinates of the pilot, the serial number of the drone and other information.
The models tested are:
|
model |
Serial number evidence |
|
Phantom 4 Pro V2.0 |
1 1VKJ2S00201K2 |
|
M INI2, |
5FSCK1601120NS , 3NZCJ8M0142TMV |
|
Mini 3 |
687CKC20017ARG , 687CKC30017F0F |
|
Mini 3 Pro |
F4XFC22AT007QM7Y , F4XFC22BT007SSPM |
|
Mavic Pro |
08RDE4N00100PE |
|
Mavic 2 |
163DF9H0013NVW，0M6DF9E0016T73 |
|
Mavic 2 Enterprise |
276DF9N001WQ16 |
|
Mavic 3 |
F4QZB21AR1AE01BW，F4QZB21AL00E02RV |
|
Air 2 |
3N3BJ7U0120553，F45TB21BT2AEG03GL |
|
Air 2S |
3YTSJ5J003158A，3YTBK9Q003025G |
|
M300 RTK |
1ZN3JC6001T570 |
|
M30 |
F4BND229H00DH4Z3 |
|
Avata |
F4QWB22C600306MQ，F4QWB228500303KL |
|
FPV |
37QBJ15BD1047B |
|
Inspire 3 |
F4Z4D235J00467T5 |
|
Mavic 3 T |
F5FJD22C500CGB5F，F5FHD233G00DW876 |
|
M350 |
F6GKB235900300NM，F6GKB235900300PG |
|
Mavic 3 pro |
F67QD234A0141767，F67QC235T0143860 |
|
Phantom 4 RTK |
0UYVE42S01DH4K5 |
|
Matrice 350 RTK |
F6GKB234M00300KY |
|
A ir 3 |
F6N8D236F00151Q2 , F6N8C23740031BL1 |
|
Mini 2 SE |
6C5CL5K0015TGC , 6C5CL3M0013YXP |
|
Code 7 2 (probably pesticide sprayer T 20 ) |
F 574 B 2219001006 Z |
|
Code 8 2 (unknown model) |
F6BUB2324001011M |
|
Code 83 (probably a pesticide sprayer T 40 )
|
