The TTSKL02P is a next-generation handheld drone detection and positioning device with enhanced capabilities for FPV drone detection. It is specifically designed to detect low-frequency FPV racing drones and can decode first-person-view (FPV) video transmission signals, enabling more effective threat awareness.
The device integrates drone spectrum detection, communication protocol analysis, Remote ID (RID) identification, and regulatory compliance functions into a single portable unit. With a lightweight design of approximately 650 g, it delivers real-time detection and early warning for 900 MHz-series drones, while accurately locating and tracking both UAVs and their operators (remote controllers).
Featuring a compact form factor, long battery life, and user-friendly operation, the TTSKL02P is ideal for a wide range of low-altitude security, defense, and counter-UAS applications, including mobile patrols and rapid deployment scenarios.
Accurately locates detected drones and displays their positions as drone icons on the electronic map (e-map) in real time.
Identifies and locates drone remote controllers (pilots), with their positions clearly shown as controller icons on the e-map.
Capable of detecting and identifying homemade FPV racing drones, with real-time analysis and decoding of FPV video transmission signals.
Automatically generates and displays navigation routes to guide operators in tracking and approaching drone pilots, ensuring efficient and user-friendly operation.
Supports identification of DJI drones using the OcuSync protocol, drones equipped with Remote ID (RID), and Wi-Fi drones with unique serial number (SN) recognition.
Provides real-time visualization of detailed drone and pilot data, including drone model, geographic coordinates, speed, altitude, pilot location, and more.
Supports customizable blacklist and whitelist settings. No alarm will be triggered when a whitelisted drone is detected.
Delivers immediate alerts through audible alarms or vibration upon drone detection.
Supports playback of historical flight trajectories, enabling effective post-incident analysis and review.
Automatically stores detection records for traceability, including serial number (SN), drone model, frequency band, and other key parameters.
Available in English, Chinese, Russian, and Portuguese.
Note: In [1] - [8], The positioning UAV is the OcuSync transmission model of DJI series. [9] GB 42590-2023、ASTM F3411 Remote ID、ASD-STAN prEN 4709-002
Technical Parameters
|
Item |
Performance Index |
Indicator Parameters |
Remarks |
|
1 |
Detection frequency band |
100MHz～6GHz |
|
|
2 |
Detection radius |
1.5~2km (urban environment) 2~3km (open area environment) |
|
|
3 |
Response time |
3~ 5s |
|
|
4 |
Positioning range |
1~2km (urban environment) 2~ 3km (open area environment) |
|
|
5 |
Detect the quantity |
≥10 sorties (simultaneously) |
|
|
6 |
Time of endurance |
3~ 4h |
|
The L02 can detect and identify a wide range of drones, including DJI drones, Wi-Fi-based UAVs, FPV drones, and many other common commercial drone models operating within the supported frequency range.
The typical detection range is up to 1.5–2 km in urban environments and up to 2–3 km in open areas, depending on terrain, signal conditions, and electromagnetic interference.
Yes. The L02 supports drone positioning and pilot (remote controller) positioning for supported drone communication protocols, displaying their locations on the built-in electronic map.
Yes. The device supports Remote ID monitoring and can recognize drones broadcasting standard RID information, helping users identify compliant UAVs in the area.
Yes. The L02 can detect and identify FPV drones and analyze FPV transmission signals in real time, enhancing situational awareness during drone monitoring operations.
The system can detect and monitor more than 10 drones simultaneously, providing real-time information for multiple targets within the coverage area.
No. The L02 supports standalone offline operation. Network connectivity is optional and can be used for additional features such as device-to-device communication.
The built-in 8000 mAh battery provides approximately 4–6 hours of operation under normal usage conditions. Battery life may vary depending on screen brightness and operating environment.
Yes. The device supports detection record storage and flight track playback, allowing users to review historical drone activity and analyze previous flight routes.
The L02 is suitable for event security, critical infrastructure protection, airport monitoring, border security, industrial facilities, law enforcement support, and general drone awareness operations where real-time drone detection and tracking are required.
