No |
Item |
Specifications |
|
1 |
Detection Bands |
30MHz~6GHz |
|
2 |
Detection Distance |
0~10km (Differences exist due to different deployment environments and drone types) |
|
3 |
Sensitivity |
≤-105dBm |
|
4 |
Detection Range |
360°Full Airspace |
|
5 |
Direction Finding Accuracy |
(RMS) 3°(hovering), 10°(moving) |
|
6 |
Positioning Method |
DroneID&RID protocol cracking positioning AOA, TDOA multi-node networking |
|
7 |
Direction Finding Bands |
2.4GHz, 5.8GHz |
|
8 |
Working Hours |
7 × 24 continuous operation |
|
9 |
Power Supply |
AC 110~240V |
|
10 |
Power Consumption |
≤100W |
|
11 |
Dimensions |
Main Device: 335mm*224mm*399mm Direction Finding Antenna:422mm*316mm* 316mm |
|
12 |
Weight |
≤13kg (Without antennas) |
|
13 |
Operating Temperature |
-25°C to +60°C |
|
14 |
IP Rating |
IP66 |
1) Passive Detection: Passively receives only and does not emit any electromagnetic signals.
2) Accurate Positioning: It can precisely detect the approach of the drone and effectively position the target.
3) Black and White List: One-click to mark the whitelist, keep the white-list drones free from countermeasure.
4) Network Positioning: By using a single device, accurate direction finding can be accomplished. By using multiple devices, networking-based positioning can be achieved, and the distance can be extended infinitely.
5) Precise Identification: It can precisely identify different drones of the same brand and model and identify the electronic fingerprint of drones.
6) Full-Covered Drone Library: Support various types of drone brands, FPV drones, Wi-Fi drones, DIY drones, etc. Cover more than 98% of the drones on the market.
